Pioneer DJ DJM-S7 Scratch-style 2-channel Performance DJ Mixer

TURNTABLI7M

This new 2-channel battle mixer gives you the freedom to customize your setup and bring your own unique style to every performance. The unit enables free use of Serato DJ Pro and it’s a Hardware Unlock device for rekordbox, so you can use performance features in either application.

Magvel Fader Pro

We’ve enhanced the feeling of the Magvel Fader Pro and boosted the rigidity of the knob mounting shaft in the vertical direction by 30 percent so you can scratch with even more confidence.

Large Performance Pads

The 8 large Performance Pads on each channel are easy to hit when you want to rapidly fire off Hot Cues and samples. And with independent pad modes, you can use 2 different features – one on each channel’s set of pads – at the same time.

Combo Pad mode

Activate Combo Pad mode in Serato DJ Pro to use 2 different pad modes on the same channel simultaneously, e.g. Hot Cue and Sampler. This reduces the need to change modes and gives you the option to combine more features to enhance your performance.

Scratch Bank

With the Scratch Bank pad mode, you can instantly load scratch samples from 4 banks that you’ve assigned in Serato DJ Pro by simply tapping a pad. You can load from a specified start point too – handy if you want to use this feature to drop in full tracks during a routine.

Large effect levers

Twist sounds on the fly by adding effects with the large levers. The DJM-S7 includes all 22 built-in Beat FX from the DJM-S11 so you can get creative with these, as well as software effects in Serato DJ Pro and rekordbox. It’s easy to change the 6 effects assigned to the FX Select buttons and you can keep an eye on the name and beat value of the one you’re using by glancing at the OLED display.

Bluetooth input: Wirelessly add audio from your phone

Simply pair your phone with the DJM-S7 via Bluetooth and you can drop sounds straight into your set. You can play loops to scratch over or use a music app to play a track requested by someone in the audience. Or simply have your mobile device connected and ready as a backup in case your laptop fails. You can play the sound directly through the master output or either of the channels.

Step 1: Press and hold the [BLUETOOTH PAIRING] button

Press and hold the [BLUETOOTH PAIRING] button for approximately 2 seconds. The unit enters its pairing state. The Bluetooth indicator blinks while the unit is in the pairing state.

Step 2: Perform the pairing procedure on your Bluetooth device

Perform the pairing procedure on your Bluetooth device while the unit is in the pairing state. The Bluetooth indicator on the unit stops blinking and lights up when the connection is established. If you use a Bluetooth device that you’ve previously paired with the unit, you can connect again by pressing the [BLUETOOTH PAIRING] button briefly.

Loop MIDI: Automated control of DJ software functions

This feature in the effects section of the DJM-S7 can control various functions in your DJ software by repeatedly sending a MIDI signal to the software in a set beat cycle. Functions including Hot Cue, sampler, and key shift-up are preassigned so you can start using Loop MIDI straight away.

Loop MIDI: Pattern A
You can create a buildup by gradually shortening the beat cycle of a snare sample which is playing in a loop.

Loop MIDI: Pattern B
You can also raise or lower the key of deck 1 or 2 track, activate sampler slot 1 or Hot Cue 1 / A, or mute the deck.

OTHER FEATURES

USB hub (USB Type-A)

Plug your DJ controllers and other devices – including selected units from other brands – into the dual USB-A ports to play with them.

MIDI controller (USB Type-B)

This device is fully MIDI assignable via USB. Send control information to external devices and use the mixer as a MIDI controller.

Serato DJ Pro

Connect your PC/Mac to use Serato DJ Pro (the mixer unlocks the software for free). Use dedicated buttons for effects and advanced Serato features including Beat Jump, Slip mode, and Quantize.

Serato DVS

Use Serato DVS to control and scratch with CDJs or turntables.

Pitch ‘n Time DJ

Serato DJ Pro Expansion Pack Voucher (Pitch ‘n Time DJ) is included. Use Pitch Play, Key Shift, and more features. The mixer is fully MIDI mappable too.

rekordbox

Connect your PC/Mac to unlock performance features in rekordbox for free and use DVS mode with the dedicated control vinyl (available separately).

Firmware Update Manager

You’ll be automatically notified when firmware updates become available.

Functions

• LOAD button (browse section) Loads a selected track to the unit. Press twice to load a track that’s loaded to another deck on which you’re pressing the [LOAD] button.
• AUTO LOOP button (loop section) Plays a loop of the specified number of beats or starts Auto Beat Loop. Press while pressing the [SHIFT] button to turn a loop on or off.
• FILTER knob Can apply a filter or an effect to the sound on any channel. There are 5 types of effect that you can assign including filter effect.
• FX SELECT buttons (FX section) The unit includes 6 buttons for selecting effects. You can assign internal effects (Beat FX), DJ software effects (software FX), or Loop MIDI functions to the buttons. There are 22 Beat FX to choose from including Fader Pitch and Helix.
• Effect lever (FX section) Applies an effect while you hold the effect lever in the [ON] position. Continues applying an effect when you leave it in the [LOCK ON] position.
• FX SELECT buttons (FX section) The unit includes 6 buttons for selecting effects. You can assign internal effects (Beat FX), DJ software effects (software FX), or Loop MIDI functions to the buttons. There are 22 Beat FX to choose from including Fader Pitch and Helix.
• PERFORMANCE PADS Activate Combo Pad mode in Serato DJ Pro to use up to 4 different pad modes simultaneously. With Scratch Bank, you can call up scratch samples that you’ve assigned in Serato.
• MAGVEL FADER PRO Adjusts the volume balance between the channel output sounds according to the selected crossfader curve setting. The new curve setting has been developed for optimal scratch performance.
• FEELING ADJUST knob Adjusts the “weight” of the crossfader.
• CURVE knob Sets the crossfader curve.
• BLUETOOTH PAIRING button Pairs the unit with a Bluetooth device.
• BLUETOOTH LEVEL knob Adjusts the volume of the Bluetooth input.
• CH 1/2 CURVE knob Sets the channel fader curve.
• Signal GND terminal Connect a turntable’s ground wire. Easy to connect but solid connection.
• CDJ/CONTROLLER terminals Connect compatible multi players or controllers.
• USB ports Connect a PC/Mac.

What’s in the box

• DJM-S7
• Power cord
• USB cable
• Warranty (for some regions)
• Quick Start Guide
• Precautions for Use
• Serato DJ Pro Expansion Pack Voucher (Pitch ‘n Time DJ)

Specifications

Main Features

MIDI Control	Assignable
Compatible DJ Software	Unlocks Serato DJ Pro rekordbox
DVS Control	Unlocks Serato DVS rekordbox
Software System Requirements	Visit serato.com for its specifications. Visit rekordbox.com for its specifications.
Bluetooth Audio Input	Version: Bluetooth standard version 5.0 Supported Codecs: SBC, AAC, Qualcomm® aptX™, Qualcomm® aptX™ Low Latency Maximum Communication Distance: Approximately 10 m in unobstructed circumstances

Specifications

Frequency Range	20 – 20000 Hz
Width	10.51 in
Height	4.25 in
Depth	15.65 in
Weight	9.92 lb
Power Consumption	24W
Power Supply	AC 100-240 V, 50 Hz / 60Hz
S/N Ratio USB	110 dB (USB) 103 dB (LINE) 88 dB (PHONO) 80 dB (MIC) 103 dB (AUX)
Distortion	0.003% (USB) 0.005% (LINE)

Master

Level Meter Size	9 segment

Channels

EQ/ISO	3 band
EQ/ISO Range	–∞ dB to +6 dB

Performance Control

Channels	2
Sound Color FX	Filter Dub Echo Noise Pitch Wide Filter
Beat FX	Echo Ducking Echo Echo Out Spiral Helix Delay Reverb Back Spin One-shot Spin Vinyl Brake One-shot Brake Flanger Phaser HP Filter LP Filter Trans Kill Roll Fader Pitch Fader Synth

Crossfader

Crossfader Type	MAGVEL FADER PRO

Mic

Mic Connection	XLR / 1/4-inch Combo Jack

Sound card

Connection	USB (Type-B)
Sample Rate	24 bit
Frequency	48 kHz

Terminals

Inputs	2 LINE (RCA) 2 PHONO (RCA) 1 MIC (XLR & 1/4 inch TRS Jack) 1 AUX (RCA)
Outputs	2 MASTER (XLR, RCA) 1 BOOTH (1/4 inch TRS Jack) 2 PHONES (1/4-inch stereo jack, 3.5-mm stereo mini-jack)
USB	2 USB A ports 2 USB B ports

* The specifications and design of this product are subject to change without notice.
