Pioneer DJ PLX-1000 Professional Direct Drive Turntable

A reborn classic

The PLX-1000 is precision engineered for the booth, drawing on 50 years’ experience of making high-end turntables. The result is a familiar layout with some next generation improvements, including a high-torque direct drive system, multi-pitch control, club-grade build and sound quality, and detachable power and audio cables.

Turn the tables

The high-torque direct drive ensures stable rotation and exceptional control – and it reaches 33⅓ rpm in just 0.3 seconds thanks to a starting torque of 4.5kg/cm (or more).

Excellent sound design

The PLX-1000’s heavy-mass, die-cast zinc chassis prevents resonance and vibrations. The lower part of the unit is reinforced with 8mm-thick resin, plus 9mm-thick, vibration-damping material at the base. Plus the rubber-insulated tone arm reduces howling effects, while rubber and springs on the dampening parts of the insulator absorb external vibrations.

Pick up the pace

Multi-tempo control lets you instantly pick up or slow down the track to ±8%, ±16% and ±50%, while a simple reset button instantly reverts to ±0%.

Flexible connectivity

Interchangeable power and audio cables can be easily connected and replaced, and pro-grade gold-plated RCA jacks ensure low impedance and an amazing sound quality.

What’s in the box

• PLX-1000
• Power cord
• Audio cable
• Ground wire
• Adapter for EP record
• Turntable sheet
• Slip mat and sheet
• Dust cover
• Head shell
• Balance, sub and shell weights
• Operating instructions

Specifications

Specifications

Width	17.83 in
Height	6.26 in
Depth	13.9 in
Weight	32.19 lb

Turntables

Drive Method	Quartz lock, servo-type, direct drive
Platter	Aluminium, die-casting diameter: 332 mm
Motor	3-phase, brushless DC motor
Braking System	Electronic brake
Rotation Speed	33⅓-45 rpm
Rotation Adjustment Range	±8, ±16, ±50 %
Wow and Flutter	< 0.01 % (Measured by obtaining signal from built-in frequency generator of motor assembly.)
Signal-to-Noise Ratio	70 dB
Starting Torque	> 4.5 kgf・cm
Start Time	Within 0.3 sec (at 33⅓ rpm)

Tone Arm

Arm Type	Universal type S-shape tone arm Gimbal-supported type bearing structure Static balance type
Overhang	0.59 in
Effective Length	9.06 in
Tracking Error	Within 3°
Height Adjustment Range	0.24 in
Stylus Pressure Variable Range	0-4 g (1 scale 0.1 g)
Cartridge Weight Single	2.5-12 g (includes mounting materials)

Terminals

Outputs	1 ANALOGUE (RCA)

* The specifications and design of this product are subject to change without notice.
